845-132 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 132POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Number of Positions | Gender | Contact Material | Read Out | Pitch | Pitch | Color | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Number of Rows [custom] | Contact Type | Card Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Wire Wrap | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | Solder | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Right Angle Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Solder | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | Solder Eyelet(s) | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Wire Wrap | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Solder | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Right Angle Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Wire Wrap | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Wire Wrap | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Solder | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Solder | 132 | Female | Copper Alloy | Dual | 0.1 " | 2.54 mm | Green | 66 | 0.25 Ám | 10 Áin | Through Hole | 2 | Cantilever | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold |
