770849 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN HOUSING RCP 10 POS 3.96MM CRIMP ST CABLE MOUNT NATURAL PACKAGE
| Part | Note | Mounting Type | Contact Type | Number of Positions | Color | Number of Rows | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Material | Fastening Type | Contact Termination | Pitch | Pitch | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 10 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 22 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 9 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 24 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 4 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 14 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 12 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 21 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 20 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
 TE Connectivity AMP Connectors | Contacts Not Included | Free Hanging (In-Line) | Female Socket | 6 | Natural | 1 | Receptacle | -55 C | 105 ░C | Nylon Polyamide (PA) | Locking Ramp | Crimp | 3.96 mm | 0.156 in | Polarizing Key |
