1802B Series
Manufacturer: Belden Inc.
Beta
⌘K
2 #24FHDPE PRFS PVC PAR
| Part | Shield Coverage | Shield Material | Usage | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Conductor Insulation | Ratings | Wire Gauge | Number of Conductors | Operating Temperature [Min] | Operating Temperature [Max] | Features | Jacket Color | Shield Type | Conductor Material | Length | Length | Cable Type | Conductor Strand [custom] | Conductor Strand [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum Polyester | Audio | 300 VDC | 9.14 mm | 0.36 in | Poly-Vinyl Chloride (PVC) | Foam Polyethylene (FPE) | UL Style CMR | 24 AWG | 4 | -30 ░C | 60 °C | Drain Wire | Violet | Foil | Copper Tinned | 304.8 m | 1000 ft | Multi-Pair | 7 | 32 AWG |
 Belden Inc. | 100 % | Aluminum Polyester | Audio | 300 VDC | 9.14 mm | 0.36 in | Poly-Vinyl Chloride (PVC) | Foam Polyethylene (FPE) | UL Style CMR | 24 AWG | 4 | -30 ░C | 60 °C | Drain Wire | Black | Foil | Copper Tinned | 304.8 m | 1000 ft | Multi-Pair | 7 | 32 AWG |
 Belden Inc. | 100 % | Aluminum Polyester | Audio | 300 VDC | 9.14 mm | 0.36 in | Poly-Vinyl Chloride (PVC) | Foam Polyethylene (FPE) | UL Style CMR | 24 AWG | 4 | -30 ░C | 60 °C | Drain Wire | Violet | Foil | Copper Tinned | 304.8 m | 1000 ft | Multi-Pair | 7 | 32 AWG |
