TVM07DS Series

Manufacturer: Amphenol Aerospace Operations

Catalog

MATRIX 38999, TRI-START SERIES I

Part	Note	Contact Shape	Connector Type	Fastening Type	Contact Size	Housing Color	Mounting Feature	Shielding	Shell Material	Shell Size - Insert	Number of Positions	Type	Shell Finish	Orientation	Mounting Type	Contact Type	Qualification	Shell Size - Insert Length	Shell Size - Insert Width
Amphenol Aerospace Operations TVM07DS-23L-2P	Contacts Not Included Insert Not Included	Circular	Receptacle Housing	Threaded	8	Silver	Bulkhead Front Side Nut	Unshielded	Aluminum Alloy	23L-2	3	For Male Pins	Nickel	N (Normal)	Panel Mount	Crimp	MIL-DTL-38999 Series III
Amphenol Aerospace Operations TVM07DS-25L-10P	Contacts Not Included Insert Not Included	Circular	Receptacle Housing	Threaded	8	Silver	Bulkhead Front Side Nut	Unshielded	Aluminum Alloy	25L-10	7	For Male Pins	Nickel	N (Normal)	Panel Mount	Crimp	MIL-DTL-38999 Series III
Amphenol Aerospace Operations TVM07DS-37-17P	Contacts Not Included Insert Not Included	Circular	Receptacle Housing	Threaded	4	Silver	Bulkhead Front Side Nut	Unshielded	Aluminum Alloy		4	For Male Pins	Nickel	N (Normal)	Panel Mount	Crimp	MIL-DTL-38999 Series III	37 mm	17 mm
Amphenol Aerospace Operations TVM07DS-23L-22P	Contacts Not Included Insert Not Included	Circular	Receptacle Housing	Threaded	8	Silver	Bulkhead Front Side Nut	Unshielded	Aluminum Alloy	23L-22	4	For Male Pins	Nickel	N (Normal)	Panel Mount	Crimp	MIL-DTL-38999 Series III
Amphenol Aerospace Operations TVM07DS-25L-22P	Contacts Not Included Insert Not Included	Circular	Receptacle Housing	Threaded	8	Silver	Bulkhead Front Side Nut	Unshielded	Aluminum Alloy	25L-22	4	For Male Pins	Nickel	N (Normal)	Panel Mount	Crimp	MIL-DTL-38999 Series III
Amphenol Aerospace Operations TVM07DS-33-22P	Contacts Not Included Insert Not Included	Circular	Receptacle Housing	Threaded	4 16	Silver	Bulkhead Front Side Nut	Unshielded	Aluminum Alloy		6	For Male Pins	Nickel	N (Normal)	Panel Mount	Crimp	MIL-DTL-38999 Series III	33 mm	22 mm
