337-076 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 76POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Gender | Card Type | Features | Termination | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Mounting Type | Flange Feature | Contact Material | Read Out | Pitch | Pitch | Number of Positions/Bay/Row [custom] | Color | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Card Guides | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Card Guides | Solder | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | Side Mount Opening Unthreaded | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Card Guides | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Solder | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | 3.96 mm | 0.156 " | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Solder | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Right Angle Through Hole | Flush Mount Top Opening Unthreaded | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Non Specified - Dual Edge | Wire Wrap | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 76 | -40 C | 105 ░C | Cantilever | Through Hole | M3 Threaded Insert Top Mount Opening | Copper Alloy | Dual | 3.96 mm | 0.156 in | 38 | Green | Gold |
