807-042 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 42POS 0.156
| Part | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Termination Rows | Contact Finish | Number of Positions | Material - Insulation | Color | Gender | Number of Rows | Pitch | Pitch | Card Type | Termination | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Read Out | Contact Type | Number of Positions [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Gold | 42 | Diallyl Phthalate (DAP) | Green | Female | 1 | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | 42 | Single | Semi Bellows | |||||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Gold | Diallyl Phthalate (DAP) | Green | Female | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder Eyelet(s) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | 42 | Dual | Semi Bellows | 84 | 0.156 " | 3.96 mm | 2 | |||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 42 | Diallyl Phthalate (DAP) | Green | Female | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Semi Bellows | 2 | 2 | 21 | Card Extender | |||||||
 EDAC Inc. | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Tin | 42 | Diallyl Phthalate (DAP) | Green | Female | 1 | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | Through Hole | Copper Alloy | 125 °C | -40 C | 42 | Single | Semi Bellows | 0.128 " | 3.25 mm | |||||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Tin | 42 | Diallyl Phthalate (DAP) | Green | Female | 1 | 3.96 mm | 0.156 in | Non Specified - Single Edge | Wire Wrap | Through Hole | Copper Alloy | 125 °C | -40 C | 42 | Single | Semi Bellows | ||||||||||
 EDAC Inc. | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Tin | 42 | Diallyl Phthalate (DAP) | Green | Female | 1 | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | Right Angle Through Hole | Copper Alloy | 125 °C | -40 C | 42 | Single | Semi Bellows | 0.128 " | 3.25 mm | |||||||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 42 | Diallyl Phthalate (DAP) | Green | Female | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Semi Bellows | 2 | 2 | 21 | Card Extender | ||||||
 EDAC Inc. | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 42 | Diallyl Phthalate (DAP) | Green | Female | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Through Hole | Copper Alloy | 125 °C | -40 C | Dual | Semi Bellows | 2 | 2 | 21 | |||||||||
 EDAC Inc. | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 42 | Diallyl Phthalate (DAP) | Green | Female | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | Dual | Semi Bellows | 0.128 " | 3.25 mm | 2 | 2 | 21 | Card Extender | ||||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Tin | 42 | Diallyl Phthalate (DAP) | Green | Female | 1 | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | Through Hole | Copper Alloy | 125 °C | -40 C | 42 | Single | Semi Bellows |
