RR Series
Manufacturer: IDEC
Beta
⌘K
GENERAL PURPOSE RELAYS RELAY PLUG-IN DPDT 10A 100VDC
| Part | Contact Form | Coil Type | Approval Agency | Mounting Type | Must Release Voltage | Contact Rating (Current) | Relay Type | Load - Max Switching | Must Operate Voltage | Coil Voltage | Contact Material | Switching Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Features | Termination Style | Operate Time | Release Time | Coil Current | Termination Style | Coil Resistance | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 IDEC | DPDT (2 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 10 VDC | 10 A | General Purpose | 300 W 2400 VA | 80 VDC | 100 VDC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Lighted Indicator RC Circuit | Plug In | 25 ms | 25 ms | ||||
 IDEC | DPDT (2 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 4.8 VDC | 10 A | General Purpose | 300 W 2400 VA | 38.4 VDC | 48 VDC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Plug In | 25 ms | 25 ms | 0.03 A | ||||
 IDEC | SPDT (1 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 3.6 VAC | 10 A | General Purpose | 300 W 2400 VA | 9.6 VAC/DC | 12 VAC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Lighted Indicator | Plug In Quick Connect | 25 ms | 25 ms | 210 mA | 0.187 in 4.7 mm | ||
 IDEC | SPDT (1 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 2.4 VDC | 10 A | General Purpose | 300 W 2400 VA | 19.2 VDC | 24 VDC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Lighted Indicator | Plug In Quick Connect | 25 ms | 25 ms | 0.06 A | 0.187 in 4.7 mm | ||
 IDEC | 3PDT (3 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 33 VAC | 10 A | General Purpose | 300 W 2400 VA | 88 VAC/DC | 110 VAC/DC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Lighted Indicator | Plug In | 25 ms | 25 ms | 23 mA | 1.68 kOhms | 11 Pin | |
IDEC | 3PDT (3 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 2.4 VDC | 10 A | General Purpose | 300 W 2400 VA | 19.2 VDC | 24 VDC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Test Button | Plug In Quick Connect | 25 ms | 25 ms | 0.06 A | 0.187 in 4.7 mm | ||
 IDEC | 3PDT (3 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 36 VAC | 10 A | General Purpose | 300 W 2400 VA | 96 VAC | 120 VAC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Plug In | 25 ms | 25 ms | 20.5 mA | 11 Pin | |||
IDEC | 3PDT (3 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 7.2 VAC | 10 A | General Purpose | 300 W 2400 VA | 19.2 VAC | 24 VAC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Lighted Indicator Test Button | Plug In Quick Connect | 25 ms | 25 ms | 105 mA | 0.187 in 4.7 mm | ||
 IDEC | ||||||||||||||||||||||
IDEC | 3PDT (3 Form C) | Non Latching | CE CSA cURus TUV | Socketable | 2.4 VDC | 10 A | General Purpose | 300 W 2400 VA | 19.2 VDC | 24 VDC | Silver (Ag) | 30 VDC 240 VAC | -25 °C | 40 °C | Plug In | 25 ms | 25 ms | 0.06 A | 11 Pin |
