16_4310-50 Series

Catalog

RF CONNECTORS / COAXIAL CONNECTORS

Part	Center Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Body Finish	Body Material	Center Contact Plating	Dielectric Material	Number of Ports	Fastening Type	Contact Termination	Connector Type	Shield Termination	Frequency - Max [Max]	Connector Style	Housing Color	Mounting Type	Impedance	Cable Group
Huber+Suhner, Inc. 16_4310-50-9-X1/033_-E
Huber+Suhner, Inc. 16_4310-50-12-X60/033_-E	Brass Bronze	-55 C	85 °C	White Bronze	Brass	Silver	Polytetrafluoroethylene (PTFE)	1	Threaded	Crimp	Plug Male Pin	Clamp	12 GHz	4.3/10	Silver	Free Hanging (In-Line) Right Angle	50 Ohms
Huber+Suhner, Inc. 16_4310-50-3-X1/003_-H	Brass	-55 C	90 °C	Silver	Brass	Silver	Polytetrafluoroethylene (PTFE)	1	Threaded	Solder	Plug Male Pin	Solder	12 GHz	4.3/10	Silver	Free Hanging (In-Line) Right Angle	50 Ohms	RG-141
Huber+Suhner, Inc. 16_4310-50-12-X1/033_-E	Brass	-55 C	90 °C	White Bronze	Brass	Silver	Polytetrafluoroethylene (PTFE)	1	Threaded	Crimp	Plug Male Pin	Clamp	13 GHz	4.3/10	Silver	Free Hanging (In-Line) Right Angle	50 Ohms	1/2" Helical
Huber+Suhner, Inc. 16_4310-50-12-Z60/033_-E	Brass Bronze	-55 C	85 °C	White Bronze	Brass	Silver	Polytetrafluoroethylene (PTFE)	1	Threaded	Crimp	Plug Male Pin	Clamp	12 GHz	4.3/10	Silver	Free Hanging (In-Line) Right Angle	50 Ohms	1/2" Helical
Huber+Suhner, Inc. 16_4310-50-12-X61/033_-E	Brass Bronze	-55 C	85 °C	White Bronze	Brass	Silver	Polytetrafluoroethylene (PTFE)	1	Threaded	Crimp	Plug Male Pin	Clamp	12 GHz	4.3/10	Silver	Free Hanging (In-Line) Right Angle	50 Ohms
Huber+Suhner, Inc. 16_4310-50-12-Z61/033_-E	Brass Bronze	-55 C	85 °C	White Bronze	Brass	Silver	Polytetrafluoroethylene (PTFE)	1	Threaded	Crimp	Plug Male Pin	Clamp	12 GHz	4.3/10	Silver	Free Hanging (In-Line) Right Angle	50 Ohms
