GBC07S Series

Catalog

CONN HEADER SMD 7POS 2.54MM

Part	Number of Positions	Style	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions Loaded	Shrouding	Contact Material	Contact Type	Connector Type	Contact Finish - Mating	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Termination	Insulation Material	Fastening Type	Contact Length - Mating [x]	Contact Length - Mating	Insulation Height	Insulation Height	Mounting Type	Insulation Color	Current Rating (Amps)	Material Flammability Rating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Mating [x]
Sullins Connector Solutions GBC07SABN-M30	7	Board to Board Cable	Square	-65 ░C	150 °C	All	Unshrouded	Phosphor Bronze	Male Pin	Breakaway Header	Gold	Tin	0.1 in	2.54 mm	Solder	Nylon 9T Polyamide (PA9T)	Push-Pull	0.23 in	5.84 mm	0.1 in	2.54 mm	Surface Mount	Black	3 A	UL94 V-0	2.54 µm	100 µin	1	10 çin	0.25 çm
Sullins Connector Solutions GBC07SFBN-M30	7	Board to Board Cable	Square	-65 ░C	150 °C	All	Unshrouded	Phosphor Bronze	Male Pin	Breakaway Header	Gold	Tin	0.1 in	2.54 mm	Solder	Nylon 9T Polyamide (PA9T)	Push-Pull	0.318 "		0.1 in	2.54 mm	Surface Mount	Black	3 A	UL94 V-0	2.54 µm	100 µin	1	10 çin	0.25 çm	8.08 mm
