09S121 Series
Manufacturer: Rosenberger
Beta
⌘K
PRECISION 2.40 CALIBRATION ADAPT
| Part | Type | Accessory Type | Specifications | For Use With/Related Products | Mating Cycles | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Body Material | Center Contact Material | Convert From (Adapter End) | Convert From (Adapter End) | Center Gender | Center Contact Plating | Mounting Type | Adapter Series | Frequency - Max [Max] | Conversion Type | Style | Impedance | Convert To (Adapter End) [custom] | Adapter Type | Voltage Rating | Connector Style [x] | Connector Style | Connector Style | Number of Ports | Contact Termination | Fastening Type | Connector Type | Shield Termination | Housing Color | Insertion Loss |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | Specialized | Calibration Adapter | 2.40 Jack Plug | Network Analyzer | |||||||||||||||||||||||||||||
 Rosenberger | 500 | Polyetheretherketone (PEEK) | 85 °C | -40 C | Stainless Steel | Beryllium Copper | APC-2.4 Male Pin OS-50 Plug | 2.4 mm | Male to Male | Gold | Free Hanging (In-Line) | RPC-2.40 to RPC-2.40 | 50 GHz | Same Series | Straight | 50 Ohms | 2.4 mm | Plug to Plug | |||||||||||||||
 Rosenberger | 500 | Polyetheretherketone (PEEK) | 85 °C | -40 C | Stainless Steel | Beryllium Copper | Gold | Free Hanging (In-Line) | 50 GHz | 50 Ohms | 150 VDC | 2.4 mm | OS-50 | APC-2.4 | 1 | Solder | Threaded | Plug Male Pin | Solder | Silver | |||||||||||||
 Rosenberger | Specialized | Calibration Adapter | 2.40 Plug Plug | Network Analyzer | |||||||||||||||||||||||||||||
 Rosenberger | 500 | Polyetheretherketone (PEEK) | 85 °C | -40 C | Stainless Steel | Beryllium Copper | APC-2.4 Male Pin OS-50 Plug | 2.4 mm | Gold | Free Hanging (In-Line) | RPC-2.40 to RPC-2.40 | 50 GHz | Same Series | Straight | 50 Ohms | 2.4 mm | Plug to Jack | 0.35 dB |
