3116-2 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN PC PIN CIRC .017DIA TINLEAD

Part	Contact Finish Thickness	Contact Finish Thickness	Terminal Type	Termination	Length - Overall [x]	Length - Overall [x]	Insulation	Mounting Type	Length - Above Flange	Length - Above Flange [x]	Flange Diameter [diameter]	Flange Diameter [diameter]	Terminal Style	Board Thickness	Board Thickness	Pin Size - Above Flange [diameter]	Pin Size - Above Flange [diameter]	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Contact Material	Contact Finish	Length - Below Flange [x]	Length - Below Flange [x]
Mill-Max Manufacturing Corp. 3116-2-00-01-00-00-08-0	200 Áin	5.08 Ám	PC Pin	Swage	0.268 in	6.81 mm	Non-Insulated	Through Hole	3.96 mm	0.156 in	1.96 mm	0.077 in	Single End	1.57 mm	0.062 "	0.017 in	0.43 mm	1.32 mm	0.052 in	Brass Alloy	Tin-Lead	2.08 mm	0.082 "
Mill-Max Manufacturing Corp. 3116-2-00-34-00-00-08-0	50 µin	1.27 µm	PC Pin	Swage	0.268 in	6.81 mm	Non-Insulated	Through Hole	3.96 mm	0.156 in	1.96 mm	0.077 in	Single End	1.57 mm	0.062 "	0.017 in	0.43 mm	1.32 mm	0.052 in	Brass Alloy	Gold	2.08 mm	0.082 "
Mill-Max Manufacturing Corp. 3116-2-00-21-00-00-08-0	20 µin	0.51 µm	PC Pin	Swage	0.268 in	6.81 mm	Non-Insulated	Through Hole	3.96 mm	0.156 in	1.96 mm	0.077 in	Single End	1.57 mm	0.062 "	0.017 in	0.43 mm	1.32 mm	0.052 in	Brass Alloy	Gold	2.08 mm	0.082 "
Mill-Max Manufacturing Corp. 3116-2-00-15-00-00-08-0	10 Áin	0.25 Ám	PC Pin	Swage	0.268 in	6.81 mm	Non-Insulated	Through Hole	3.96 mm	0.156 in	1.96 mm	0.077 in	Single End	1.57 mm	0.062 "	0.017 in	0.43 mm	1.32 mm	0.052 in	Brass Alloy	Gold	2.08 mm	0.082 "
Mill-Max Manufacturing Corp. 3116-2-00-80-00-00-08-0	200 Áin	5.08 Ám	PC Pin	Swage	0.268 in	6.81 mm	Non-Insulated	Through Hole	3.96 mm	0.156 in	1.96 mm	0.077 in	Single End	1.57 mm	0.062 "	0.017 in	0.43 mm	1.32 mm	0.052 in	Brass Alloy	Tin	2.08 mm	0.082 "
