NCP13992 Series

Current Mode Resonant Controller with Integrated High Voltage Drivers, Enhanced Light Load

Catalog

Current Mode Resonant Controller with Integrated High Voltage Drivers, Enhanced Light Load

Part	Supplied Contents	Utilized IC / Part	Voltage - Input [Max]	Voltage - Input [Min]	Current - Output	Main Purpose	Outputs and Type	Outputs and Type	Voltage - Output	Regulator Topology	Board Type	Output Isolation	Voltage - Start Up	Voltage - Breakdown	Control Features	Package / Case [y]	Package / Case	Package / Case	Package / Case [x]	Duty Cycle	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Mounting Type	Fault Protection	Frequency - Switching [Min]	Frequency - Switching [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package	Topology
ON Semiconductor NCP13992AIOGEVB	Board(s)	NCP13992 NCP1616 NCP4306 NCP431	265 VAC	95 VAC	20 A	AC/DC Primary and Secondary Side with PFC	Isolated	1	12 V	Flyback	Fully Populated
ON Semiconductor NCP13992ANDR2G												Isolated	15.8 V	600 V	Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992ATDR2G												Isolated	15.8 V	600 V	EN Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992AHDR2G												Isolated	9 V		EN Frequency Control Soft Start Sync	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992AJDR2G												Isolated	9 V		EN Frequency Control Soft Start Sync	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992AUDR2G												Isolated	11.9 V	600 V	EN Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992CBDR2G												Isolated	11.9 V	600 V	Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Over Load Over Temperature Over Voltage Short Circuit UVLO	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Flyback Secondary Side SR
ON Semiconductor NCP13992AKDR2G												Isolated	15.8 V	600 V	EN Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992ADDR2G												Isolated	15.8 V	600 V	EN Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge
ON Semiconductor NCP13992AWDR2G												Isolated	11.9 V	600 V	EN Frequency Control Soft Start	3.9 mm	16-SOIC	14 Leads	0.154 in	50 %	9.5 V	20 V	Surface Mount	Current Limiting Open Loop Over Load Over Temperature Over Voltage Short Circuit	20 kHz	750 kHz	150 °C	-50 °C	16-SOIC	Half-Bridge

Catalog

Current Mode Resonant Controller with Integrated High Voltage Drivers, Enhanced Light Load

Key Features

• Quiet Skip Mode technique

• Current Mode Control Scheme

• Automatic Dead−time with Maximum Dead−time Clamp

Description

The NCP13992 is a high performance current mode controller for half bridge resonant converters. This controller implements 600 V gate drivers, simplifying layout and reducing external component count. The built−in Brown−Out input function eases implementation of the controller in all applications. In applications where a PFC front stage is needed, the NCP13992 features a dedicated output to drive the PFC controller. This feature together with dedicated quiet skip mode technique further improves light load efficiency of the whole application. The NCP13992 provides a suite of protection features allowing safe operation in any application. This includes: overload protection, over−current protection to prevent hard switching cycles, brown−out detection, open optocoupler detection, automatic dead−time adjust, overvoltage (OVP) and overtemperature (OTP) protections.
