895-060 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 60POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Number of Positions/Bay/Row | Color | Read Out | Gender | Contact Finish Thickness | Contact Finish Thickness | Termination | Card Type | Mounting Type | Number of Positions | Pitch | Pitch | Contact Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Termination Rows | Number of Positions/Bay/Row [custom] | Number of Rows | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Non Specified - Dual Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | 125 °C | -40 C | Gold | Black | Single | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 60 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | 125 °C | -40 C | Gold | Black | Single | Female | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Single Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 60 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.116 " | 2.95 mm | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Floating Bobbin Top Mount Opening | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | Board Edge Straddle Mount | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 4-40 Threaded Insert Top Mount Opening | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.156 " | 3.96 mm | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | Right Angle Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.128 " | 3.25 mm | 125 °C | -40 C | Gold | Black | Single | Female | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Non Specified - Single Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 60 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | Through Hole | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | M3 Threaded Insert Top Mount Opening | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 0.128 " | 3.25 mm | 125 °C | -40 C | Gold | 30 | Black | Dual | Female | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | Board Edge Straddle Mount | 60 | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Side Mount Opening Unthreaded | Card Extender |
