895-021 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 21POS 0.100
...
| Part | Termination Rows | Material - Insulation | Contact Finish | Number of Rows | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Contact Material | Number of Positions/Bay/Row [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Termination | Mounting Type | Card Type | Gender | Number of Positions | Color | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | Wire Wrap | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | M3 Threaded Insert Top Mount Opening | Cantilever | Solder | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | Wire Wrap | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | Cantilever | Solder | Right Angle Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | 4-40 Threaded Insert Top Mount Opening | Cantilever | Wire Wrap | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | Wire Wrap | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | 0.156 " | 3.96 mm | Cantilever | Solder | Right Angle Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | 0.128 " | 3.25 mm | Cantilever | Solder | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Cantilever | Solder | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 1 | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | 21 | 0.156 " | 3.96 mm | Cantilever | Solder | Through Hole | Non Specified - Single Edge | Female | 21 | Black | 0.25 Ám | 10 Áin |
