846-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 31POS 0.125
| Part | Termination Rows | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Contact Finish | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row [custom] | Contact Type | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Number of Positions [custom] | Gender | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Termination | Color | Mounting Type | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 3.25 mm | 0.128 " | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Copper Alloy | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 3.25 mm | 0.128 " | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Green | Right Angle Through Hole | Copper Alloy | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 3.25 mm | 0.128 " | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 3.25 mm | 0.128 " | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Copper Alloy | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Green | Right Angle Through Hole | Copper Alloy | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 3.25 mm | 0.128 " | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Green | Through Hole | Copper Alloy | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Single | Gold | Non Specified - Single Edge | 2.95 mm | 0.116 " | 31 | Cantilever | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 31 | Female | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Copper Alloy | Floating Bobbin Top Mount Opening |
