DIN-Power F Series
Manufacturer: HARTING
Beta
⌘K
CONNECTOR,DIN-41612,PCB MOUNT,RECEPT,32 CONTACTS,PIN,0.2 PITCH,PC TAIL TERMINAL ROHS COMPLIANT: YES
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Material - Insulation | Material Flammability Rating | Current Rating (Amps) | Termination | Contact Finish | Contact Finish Thickness | Level, Class [custom] | Pitch | Pitch | Mounting Type | Number of Positions | Connector Type | Number of Rows [custom] | Number of Positions Loaded | Style | Number of Positions Loaded | Level, Class | Features | Number of Positions Loaded [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | 6 A | Solder | Gold Gold-Palladium | Flash | 1 | 0.1 " | 2.54 mm | Right Angle Through Hole | 48 | Header Male Pins | 3 | 32 | F | ||||
 HARTING | Thermoplastic Glass Filled | UL94 V-0 | Solder | Gold | 0.2 in | 5.08 mm | Through Hole | 48 | Receptacle Female Sockets | 3 | F | All | |||||||||
 HARTING | -40 C | 105 ░C | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | 6 A | Press-Fit | 1 | 0.15 in | 3.81 mm | Through Hole | 48 | Receptacle Female Sockets | 3 | F | All | ||||||
 HARTING | -55 C | 125 °C | 6 A | Wire Wrap | Gold | 0.15 in | 3.81 mm | Through Hole | 48 | Receptacle Female Sockets | 3 | 32 | F | 3 | |||||||
 HARTING | Thermoplastic Glass Filled | UL94 V-0 | Wire Wrap | 0.2 in | 5.08 mm | Panel Mount Through Hole | 48 | Receptacle Female Sockets | 3 | 32 | F | ||||||||||
 HARTING | Thermoplastic Glass Filled | UL94 V-0 | Solder | 0.2 in | 5.08 mm | Right Angle Through Hole | 48 | Header Male Pins | 3 | F | All | Mounting Clips | |||||||||
 HARTING | -55 C | 125 °C | Glass Filled Nylon Polyamide (PA) | UL94 V-0 | 15 A | Solder | Gold-Palladium | Flash | 0.1 " | 2.54 mm | Right Angle Through Hole | 48 | Header Male Pins | 3 | F | 48 | |||||
HARTING | -55 C | 125 °C | Thermoplastic Glass Filled | UL94 V-0 | 6 A | Solder Lug | Gold | 1 | 0.2 in | 5.08 mm | Panel Mount | 48 | Receptacle Female Sockets | 3 | F | All |
