726-040 Series
Manufacturer: EDAC Inc.
Catalog
3.18MM STRAIGHT 40P -40℃~+105℃ PLUGIN,P=3.18MM EDGEBOARD CONNECTORS ROHS
| Part | Number of Positions | Card Type | Material - Insulation | Contact Finish | Termination Rows | Termination | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions/Bay/Row [custom] | Read Out | Contact Type | Color | Gender | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Mounting Type | Pitch [x] | Pitch [x] | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 40 | Non Specified - Single Edge | Polyester Thermoplastic | Gold | 1 | Press-Fit Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 40 | Single | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 1 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | |||
 EDAC Inc. | 40 | Non Specified - Dual Edge | Polyester Thermoplastic | Gold | 2 | Press-Fit Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 2 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | 20 | 20 | 20 | |
 EDAC Inc. | 40 | Non Specified - Dual Edge | Polyester Thermoplastic | Gold | 2 | Press-Fit | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 2 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | 20 | 20 | 20 | |
 EDAC Inc. | 40 | Non Specified - Dual Edge | Polyester Thermoplastic | Gold | 2 | Press-Fit | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 2 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | 20 | 20 | 20 | |
 EDAC Inc. | 40 | Non Specified - Single Edge | Polyester Thermoplastic | Gold | 1 | Press-Fit | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 40 | Single | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 1 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | |||
 EDAC Inc. | 40 | Non Specified - Dual Edge | Polyester Thermoplastic | Gold | 2 | Press-Fit Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 2 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | 20 | 20 | 20 | |
 EDAC Inc. | 40 | Non Specified - Single Edge | Polyester Thermoplastic | Gold | 1 | Press-Fit Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 40 | Single | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 1 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | |||
 EDAC Inc. | 40 | Non Specified - Single Edge | Polyester Thermoplastic | Gold | 1 | Press-Fit Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 40 | Single | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 1 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | |||
EDAC Inc. | 40 | Non Specified - Single Edge | Polyester Thermoplastic | Gold | 1 | Press-Fit | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 40 | Single | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 1 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm | |||
 EDAC Inc. | 40 | Non Specified - Single Edge | Polyester Thermoplastic | Gold | 1 | Press-Fit Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 40 | Single | Cantilever | Black | Female | 0.76 Ám | 30 Áin | 1 | -40 °C | 105 ░C | Copper Alloy | Through Hole | 0.125 in | 3.18 mm |
