2EDF5215 Series
Manufacturer: INFINEON
Beta
⌘K
THE EICEDRIVER 2ED4820-EM IS A SMART HIGH-SIDE N-CHANNEL MOSFET GATE DRIVER WITH TWO OUTPUTS CONTROLLED VIA SPI FOR 48V INDUSTRY AND AUTOMOTIVE APPLICATIONS.
| Part | Gate Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Drivers | Logic Voltage - VIL, VIH | Rise / Fall Time (Typ) | Rise / Fall Time (Typ) | Driven Configuration | Channel Type | Input Type | Mounting Type | Current - Peak Output (Source, Sink) [custom] | Current - Peak Output (Source, Sink) [custom] | Voltage - Supply [Max] | Voltage - Supply [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | MOSFET (N-Channel) N-Channel MOSFET | -40 °C | 150 °C | 2 | 0.4 V 2.6 V | 3 µs | 3 µs | High-Side | Independent | Non-Inverting | Surface Mount | 300 mA | 1.3 A | 70 VDC | 20 VDC |
