FP100R06 Series
Manufacturer: INFINEON
Beta
⌘K
THE FP100R06KE3 IS A PIM THREE PHASE INPUT RECTIFIER IGBT3 - E3 MODULE IN A ECONOPIM™ 3 HOUSING FOR INDUSTRIAL APPLICATIONS UP TO 600 V AND 100 A.
| Part | Current - Collector Cutoff (Max) [Max] | Current - Collector (Ic) (Max) [Max] | Input Capacitance (Cies) @ Vce | Package / Case | NTC Thermistor | Vce(on) (Max) @ Vge, Ic | Supplier Device Package | Mounting Type | Input | Configuration | Power - Max [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Collector Emitter Breakdown (Max) [Max] | IGBT Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | 1 mA | 100 A | 6.2 nF 25 V | Module | 1.9 V | Module | Chassis Mount | Standard | Three Phase Inverter | 335 W | -40 C | 150 °C | 600 V | Trench Field Stop |
