IPW60R190 Series
Manufacturer: INFINEON
Beta
⌘K
COOLMOS™ P6 N-CHANNEL SUPERJUNCTION MOSFET 600 V ; TO-247 PACKAGE; 190 MOHM; PRICE/PERFORMANCE
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Drain to Source Voltage (Vdss) | Package / Case | FET Type | Mounting Type | Supplier Device Package | Drive Voltage (Max Rds On, Min Rds On) | Technology | Power Dissipation (Max) | Rds On (Max) @ Id, Vgs | Input Capacitance (Ciss) (Max) @ Vds [Max] | Vgs (Max) | Current - Continuous Drain (Id) @ 25°C | Gate Charge (Qg) (Max) @ Vgs | Vgs(th) (Max) @ Id |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | 150 °C | -55 °C | 600 V | TO-247-3 | N-Channel | Through Hole | PG-TO247-3 | 10 V | MOSFET (Metal Oxide) | 151 W | 190 mOhm | 1750 pF | 20 V | 20.2 A | 11 nC | 4.5 V |
