Liquid Level Sensors LLS
Liquid Level Sensors LLS
| Part | Switch Actuation Level | Switch Actuation Level | Minimum Liquid Specific Gravity [Min] | Current | Voltage Rating | Material - Housing & Prism | Mounting Type | Output Configuration | Output Type | Operating Temperature [Min] | Operating Temperature [Max] | Type | Switch Actuation Level |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | 8 mm 20 mm | 0.3149 " 0.4641 " | 0.85 | 600 mA | 120 VDC 240 VAC | Polypropylene (PP) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -20 ░C | 100 °C | Liquid Temperature | |
 Sensata-Crydom | 0.354 in 0.945 in | 0.85 | 600 mA | 120 VDC 240 VAC | Polyphenylene Sulphide (PPS) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -10 °C | 120 °C | Liquid Temperature | ||
 Sensata-Crydom | 8 mm 20 mm | 0.3149 " 0.4641 " | 0.85 | 1 A | 300 VDC 300 VAC | Polypropylene (PP) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -20 ░C | 100 °C | Liquid Temperature | |
 Sensata-Crydom | 8 mm 20 mm | 0.3149 " 0.4641 " | 0.85 | 600 mA | 120 VDC 240 VAC | Polypropylene (PP) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -20 ░C | 100 °C | Liquid Temperature | |
 Sensata-Crydom | 0.276 in 0.464 in | 0.85 | 1 A | 300 VDC 300 VAC | Nylon | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | Liquid Temperature | 7 mm 20 mm | |||
 Sensata-Crydom | 0.354 in 0.945 in | 0.85 | 600 mA | 120 VDC 240 VAC | Polyphenylene Sulphide (PPS) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -10 °C | 120 °C | Liquid Temperature | ||
 Sensata-Crydom | 0.354 in 0.945 in | 0.85 | 1 A | 300 VDC 300 VAC | Polyphenylene Sulphide (PPS) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -10 °C | 120 °C | Liquid Temperature | ||
 Sensata-Crydom | 0.276 in 0.464 in | 0.85 | 600 mA | 120 VDC 240 VAC | Nylon | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | Liquid Temperature | 7 mm 20 mm | |||
 Sensata-Crydom | 8 mm 20 mm | 0.3149 " 0.4641 " | 0.85 | 1 A | 300 VDC 300 VAC | Polypropylene (PP) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -20 ░C | 100 °C | Liquid Temperature | |
 Sensata-Crydom | 0.354 in 0.945 in | 0.85 | 1 A | 300 VDC 300 VAC | Polyphenylene Sulphide (PPS) | Male 1/2" (12.7mm) NPT | SPST-NC/NO | Switch (Single Float) | -10 °C | 120 °C | Liquid Temperature |
