633-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
633 SERIES RIGHT ANGLE D-SUB PLU
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Material Flammability Rating | Shell Material, Finish | Number of Positions | Connector Style | Number of Rows [custom] | Flange Feature | Backset Spacing | Backset Spacing | Contact Finish | Features | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Mounting Type | Shell Size, Connector Layout | Termination | Contact Type | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | Housing/Shell (Unthreaded) | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 30 Áin | 0.76 Ám | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | ||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | 4-40 Mating Side Female Screwlock | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | 4-40 | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 15 µin | 0.38 µm | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | Housing/Shell | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 30 Áin | 0.76 Ám | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | 4-40 | |
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | 4-40 Mating Side Female Screwlock | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 30 Áin | 0.76 Ám | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | ||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | 4-40 Mating Side Female Screwlock | 8.89 mm | 0.35 in | Gold | Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 30 Áin | 0.76 Ám | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | ||
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | Housing/Shell | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 30 Áin | 0.76 Ám | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | 4-40 | |
 EDAC Inc. | -55 C | 85 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | Housing/Shell | 8.89 mm | 0.35 in | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | Flash | 4-40 | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | 4-40 | 8.89 mm | 0.35 in | Gold | Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 30 Áin | 0.76 Ám | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Polyester Thermoplastic | UL94 V-0 | Nickel Plated Steel | 44 | D-Sub High Density | 3 | Housing/Shell (M3) | 8.89 mm | 0.35 in | Gold | Grounding Indents Mounting Brackets Shielded | Plug Male Pins | 3 A | Board Edge Right Angle Through Hole | 3 | Solder | Signal | Flash |
