M80-782 Series

Catalog

3 POS. MALE SIL VERTICAL THROUGHBOARD CONN. LATCHES ROHS COMPLIANT: YES

Part	Mated Stacking Heights	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Shrouding	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Insulation Color	Voltage Rating	Contact Material	Connector Type	Number of Rows	Contact Length - Post	Contact Length - Post	Insulation Height [z]	Insulation Height [z]	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Contact Shape	Style	Fastening Type	Contact Type	Contact Finish - Mating	Material Flammability Rating	Mounting Type	Number of Positions Loaded	Insulation Material	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Number of Positions
Harwin Inc. M80-7820342	7.23 mm 10.2 mm 13.46 mm	118.1 µin	3 µm	Shrouded - 4 Wall	2.2 A	-55 C	125 °C	Solder	Black	120 VDC	Phosphor Bronze	Header	1	4.5 mm	0.177 in	0.219 in	5.56 mm	29.5 µin	0.75 µm	Circular	Board to Board Cable	Latch Lock	Male Pin	Gold	UL94 V-0	Through Hole	All	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin
Harwin Inc. M80-7820222	7.23 mm 10.2 mm 13.46 mm	118.1 µin	3 µm	Shrouded - 4 Wall	2.2 A	-55 C	125 °C	Solder	Black	120 VDC	Phosphor Bronze	Header	1	4.5 mm	0.177 in	0.219 in	5.56 mm	29.5 µin	0.75 µm	Circular	Board to Board Cable	Latch Lock	Male Pin	Gold	UL94 V-0	Through Hole	All	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead	2
Harwin Inc. M80-7820422	7.23 mm 10.2 mm 13.46 mm	118.1 µin	3 µm	Shrouded - 4 Wall	2.2 A	-55 C	125 °C	Solder	Black	120 VDC	Phosphor Bronze	Header	1	4.5 mm	0.177 in	0.219 in	5.56 mm	29.5 µin	0.75 µm	Circular	Board to Board Cable	Latch Lock	Male Pin	Gold	UL94 V-0	Through Hole	All	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead	4
Harwin Inc. M80-7820642	7.23 mm 10.2 mm 13.46 mm	118.1 µin	3 µm	Shrouded - 4 Wall	2.2 A	-55 C	125 °C	Solder	Black	120 VDC	Phosphor Bronze	Header	1	4.5 mm	0.177 in	0.219 in	5.56 mm	29.5 µin	0.75 µm	Circular	Board to Board Cable	Latch Lock	Male Pin	Gold	UL94 V-0	Through Hole	All	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin	6
