4900 Series
Manufacturer: Keystone Electronics
Beta
⌘K
TEST PLUGS & TEST JACKS SLOTTED PC TEST PT .39" TIN PLATE
| Part | Mounting Type | Material - Insulation | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Hole Diameter [diameter] | Hole Diameter [diameter] | Plating | Material - Body | Type | Tab Width | Tab Width | Contact Finish | Tab Thickness | Tab Thickness | Features | Gender | Termination | Terminal Type | Contact Material | Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Keystone Electronics | Through Hole | No Insulation | 0.275 " | 0.118 in | 6.99 mm | 3 mm | 0.055 in | 1.4 mm | Tin | Brass | PC Test Point Slotted | |||||||||||
 Keystone Electronics | Through Hole | No Insulation | 0.071 " | 0.098 in | 1.8 mm | 2.5 mm | 0.039 in | 1 mm | Tin | Brass | PC Test Point Slotted | |||||||||||
 Keystone Electronics | Right Angle Through Hole | 0.11 " | 2.79 mm | Tin | 0.02 in | 0.51 mm | UL Approved | Male | Solder | Standard | Brass | Non-Insulated |
