RACM140E-K Series
Manufacturer: Recom Power
Beta
⌘K
AC/DC OPEN FRAME POWER SUPPLY (PSU), ITE, INDUSTRIAL, HOUSEHOLD, MEDICAL, 1 OUTPUT, 140 W
| Part | Voltage - Output 1 | Standard Number | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Efficiency | Number of Outputs | Type | Voltage - Isolation | Voltage - Input [Min] | Voltage - Input [Max] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Features | Mounting Type | Power (Watts) | Current - Output 1 | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | 24 V | 60335-1 60601-1 62368-1 | 90 °C | -40 °C | Household Appliances ITE (Commercial) Medical | 88 % | 1 | Open Frame | 4.2 kV | 80 VAC 120 VDC | 264 VAC 370 VDC | 3.2 " | 1.5 in | 81.3 mm | 144.8 mm | 5.7 " | 38.1 mm | PFC Universal Input | Chassis Mount | 140 W | 5.8 A | CE cURus |
 Recom Power | 48 V | 60335-1 60601-1 62368-1 | 90 °C | -40 °C | Household Appliances ITE (Commercial) Medical | 90 % | 1 | Enclosed | 4.2 kV | 80 VAC 120 VDC | 264 VAC 370 VDC | 3.2 " | 1.6 " | 81.3 mm | 144.8 mm | 5.7 " | 40.6 mm | PFC Universal Input | Chassis Mount | 140 W | 2.9 A | CE cURus |
