WTB12 Series
Manufacturer: SICK, Inc.
Beta
⌘K
SENSOR PROXIMITY 350MM NPN
| Part | Cable Length | Cable Length | Adjustment Type | Response Time | Light Source | Operating Temperature [Min] | Operating Temperature [Max] | Connection Method | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Method | Sensing Distance [Max] | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Min] | Output Configuration | Ingress Protection | Light Source |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SICK, Inc. | 78.74 " | 2 m | 5-Turn Potentiometer Adjustable | 330 µs | Red (640nm) | -40 °C | 60 °C | Cable | 10 VDC | 30 VDC | Proximity | 350 mm | 20 mm | 13.78 " | 0.787 " | NPN | ||
 SICK, Inc. | 78.74 " | 2 m | 5-Turn Potentiometer Adjustable | 330 µs | Infrared (880nm) | -40 °C | 60 °C | Cable | 10 VDC | 30 VDC | Proximity | 60 cm | 20 mm | 23.622 in | 0.787 " | PNP | ||
 SICK, Inc. | 78.74 " | 2 m | 5-Turn Potentiometer Adjustable | 330 µs | Infrared (880nm) | -40 °C | 60 °C | Cable | 10 VDC | 30 VDC | Proximity | 60 cm | 20 mm | 23.622 in | 0.787 " | NPN | IP66 IP67 IP69K | |
 SICK, Inc. | 5-Turn Potentiometer Adjustable | 330 µs | Red LED | -40 C | 60 °C | Connector M12 4POS | 10 VDC | 30 VDC | 350 mm | 20 mm | 13.78 " | 0.787 " | PNP - Dark-ON/Light-ON - Selectable | IP66 IP67 IP69K | ||||
SICK, Inc. | 196.85 in | 5 m | 5-Turn Potentiometer Adjustable | 330 µs | Red (640nm) | -40 °C | 60 °C | Cable | 10 VDC | 30 VDC | Proximity | 350 mm | 20 mm | 13.78 " | 0.787 " | NPN | IP66 IP67 IP69K | |
SICK, Inc. | 5-Turn Potentiometer Adjustable | 330 µs | Infrared (880nm) | -40 °C | 60 °C | Connector M12 | 10 VDC | 30 VDC | Proximity | 60 cm | 20 mm | 23.622 in | 0.787 " | NPN | ||||
 SICK, Inc. | Adjustable | 330 µs | Red (640nm) | -40 °C | 60 °C | Connector M12 | 10 VDC | 30 VDC | Proximity | 350 mm | 20 mm | 13.78 " | 0.787 " | NPN | IP66 IP67 | |||
 SICK, Inc. | 5-Turn Potentiometer Adjustable | 330 µs | Infrared (880nm) | -40 °C | 60 °C | Connector M12 | 10 VDC | 30 VDC | Proximity | 60 cm | 20 mm | 23.622 in | 0.787 " | PNP | ||||
 SICK, Inc. | 5-Turn Potentiometer Adjustable | 330 µs | Infrared | -40 C | 60 °C | Connector M12 4POS | 10 VDC | 30 VDC | 60 cm | 20 mm | 23.622 in | 0.787 " | PNP - Dark-ON/Light-ON - Selectable | IP66 IP67 IP69K | 850 nm | |||
SICK, Inc. | Adjustable | 330 µs | Infrared (880nm) | -40 °C | 60 °C | Connector M12 | 10 VDC | 30 VDC | Proximity | 60 cm | 20 mm | 23.622 in | 0.787 " | NPN |
