SMC Series

Manufacturer: Metcal

Catalog

SOLDERING TIP, SMC-8 SERIES, BLADE, 25 MM, INCREASED THERMAL MASS

Part	Height	Height	Tip Shape	Length	Length	For Use With/Related Products	Tip Chip Size	Temperature Range	Temperature Range	Width [x]	Width [x]	Tip Type	Width [y]	Width [y]	Diameter [diameter]	Diameter [diameter]	Width	Width
Metcal SMC-8BL0025H	0.02 in	0.5 mm	Blade	9.1 mm	0.358 in	MX-500 MX-5200	Chip	420 °C	788 °F	25 mm	0.984 "	Rework
Metcal SMC-9BL0015H	0.02 in	0.5 mm	Blade	9.1 mm	0.358 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E		510 °C	950 °F	15 mm	0.591 in	Rework
Metcal SMC-5HF0030V			Hoof	11.6 mm	0.457 in	CV-500 CV-5200 MX-500 MX-5000 MX-5200						Rework	0.11 in	2.8 mm
Metcal SMC-6KN0050P			Knife	13.2 mm	0.52 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	PLCC	357 °C	675 °F	5 mm	0.197 in	Rework
Metcal SMC-9KN0050X			Knife	13.2 mm	0.52 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E	PLCC	510 °C	950 °F	5 mm	0.197 in	Rework
Metcal SMC-5HK0005S			Hoof	15.24 mm	0.6 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E		302 °C	576 °F			Rework			0.02 in	0.51 mm
Metcal SMC-6TN1986S			Tunnel	12 mm	0.472 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E		357 °C	675 °F			Rework					0.059 in	1.5 mm
Metcal SMC-5HK0008S			Conical	16.5 mm	0.65 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E		302 °C	576 °F			Rework			0.03 in	0.76 mm
Metcal SMC-6KN0048S			Knife	16.5 mm	0.65 in	CV-500 CV-5200 CV-H1-AV CV-H7-AV HMX-500 MX-5000 MX-5200 MX-H1-AV MX-H7-SF MX-RM3E MX-RM6E		357 °C	675 °F	4.83 mm	0.19 in	Rework
Metcal SMC-8HF0015V			Hoof	11.6 mm	0.457 in	MX-500 MX-5200	Chip	420 °C	788 °F			Rework
