US5U2 Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
MOSFET N-CH 30V 1.4A TUMT5
| Part | Package / Case | Operating Temperature | Drive Voltage (Max Rds On, Min Rds On) [Max] | Drive Voltage (Max Rds On, Min Rds On) [Min] | Drain to Source Voltage (Vdss) | Supplier Device Package | Technology | Power Dissipation (Max) | FET Type | FET Feature | Rds On (Max) @ Id, Vgs [Max] | Vgs(th) (Max) @ Id | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds [Max] | Current - Continuous Drain (Id) @ 25°C | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 6-SMD (5 Leads) Flat Leads | 150 °C | 4 V | 10 V | 30 V | TUMT5 | MOSFET (Metal Oxide) | 1 W | N-Channel | Schottky Diode (Isolated) | 240 mOhm | 2.5 V | 20 V | 70 pF | 1.4 A | Surface Mount |
