1393315 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
AUTOMOTIVE RELAY, 24 VDC, 130 A, SPST-NO-DM, PANEL MOUNT, SCREW, HCR 150 SERIES
| Part | Coil Resistance | Contact Material | Coil Power | Termination Style | Coil Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Must Release Voltage | Coil Type | Must Operate Voltage | Features | Contact Rating (Current) | Release Time | Switching Voltage | Operate Time | Mounting Type | Contact Form | Coil Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 141 Ohms | Silver Tin Oxide (AgSnO) | 4.1 W | Screw Terminal | 24 VDC | 125 °C | -40 C | 2.4 VDC | Non Latching | 14.4 VDC | IP67 - Dust Tight Waterproof | 130 A | 8 ms | 24 VDC | 25 ms | Chassis Mount | SPST-NO (DM) (1 Form X) | 170.2 mA |
 TE Connectivity AMP Connectors | 37 Ohms | Silver Tin Oxide (AgSnO) | 3.9 W | Screw Terminal | 12 VDC | 125 °C | -40 C | 1.2 VDC | Non Latching | 7.2 VDC | 130 A | 8 ms | 25 ms | Chassis Mount | SPST-NO (1 Form A) | |||
