dart Series

Catalog

CAMERAS & CAMERA MODULES THE BASLER DAA3840-45UM (S-MOUNT) USB 3.0 CAMERA WITH THE SONY IMX334 CMOS SENSOR DELIVERS 45 FRAMES PER SECOND AT 8.3 MP RESOLUTION. THIS MODEL COMES WITH A S-MOUNT.

Part	Sensor	Color	Shutter	Frames per Second	Interface	Height (Max) [diameter]	Height (Max) [Max] [diameter]	Lens Mount	Resolution [y]	Resolution [x]	Mounting Type	Package / Case	Type	Pixel Size [x]	Pixel Size [y]	Size / Dimension	Size / Dimension	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Height (Max) [z]	Height (Max) [z]	Voltage - Supply	Operating Temperature [Max]	Operating Temperature [Min]	Active Pixel Array [x]	Active Pixel Array [y]	Supplied Contents	Sensing Range	Contents	Sensor Type	Utilized IC / Part	Sensitivity	Voltage - Supply [Max]	Voltage - Supply [Min]	Active Pixel Array [custom]	Active Pixel Array [custom]	For Use With/Related Products	Accessory Type
Basler Inc. 108271	IMX334	Monochrome	Rolling	45 Frames per Second	USB 3.0	19.9 mm	0.783 in	S	2160	3841	Chassis Mount	Module	CMOS	2 µm	2 µm	29 mm 29.3 mm	1.142 in 1.153 in
Basler Inc. 108009	MT9P031	RGB	Rolling	60 Frames per Second	MIPI			S	1944 pixels	2592 pixels	Chassis Mount	Module	CMOS	2.2 µm	2.2 µm			29 mm	29 mm	1.142 in	1.142 in	17.5 mm	0.689 in
Basler Inc. 106983				60 Frames per Second								Module	CMOS	4.5 µm	4.5 µm									3.4 V	75 ░C	0 °C	1600	1200
Basler Inc. 108320					BCON																								Accessories Board(s) Cable(s) Power Supply	13 Megapixel	Accessories Board(s) Cable(s) Power Supply	Image Sensor	AR1335	13 fps
Basler Inc. 108221		RGB	Rolling	30	MIPI			S	2160	3840	Chassis Mount	Module	CMOS	2.1 µm	2.1 µm			29 mm	29 mm	1.142 in	1.142 in	17.5 mm	0.689 in
Basler Inc. 108275	IMX334	RGB	Rolling	45 Frames per Second	USB 3.0	19.9 mm	0.783 in	CS	2160	3845	Chassis Mount	Module	CMOS	2 µm	2 µm	29 mm 29.3 mm	1.142 in 1.153 in
Basler Inc. 108220				30								Module	CMOS	2.1 µm	2.1 µm										50 °C	0 °C									5.5 V	4.5 V	2160	3840
Basler Inc. 2200000068																																							Cameras	Cable
Basler Inc. 106683				54 per Second								Module	CMOS	3.75 µm	3.75 µm									3.4 V	75 ░C	0 °C	1280	960
Basler Inc. 106982	EV76C570	Monochrome	Global	60 Frames per Second	USB 3.0	19.9 mm	0.783 in	S	1200 Pixels	1600	Chassis Mount	Module	CMOS	4.5 µm	4.5 µm	29 mm 29.3 mm	1.142 in 1.153 in
