WDR-60 Series

Catalog

AC/DC DIN RAIL SUPPLY 48V 60W

Part	Approval Agency	Number of Outputs	DC Voltage - Input (Min) [Min]	Power (Watts)	Features	Voltage - Output 1	Voltage - Isolation	Input Type	Current - Output (Max) [Max]	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Operating Temperature [Max]	Operating Temperature [Min]	DC Voltage - Input (Max) [Max]	Applications	Efficiency	Current - Output (Max)
MEAN WELL USA Inc. WDR-60-48	CE EAC TUV UL	1	254 V	60 W	Adjustable Output	48 V	4.7 kV	AC or DC	1.25 A	550 VAC	180 VAC	85 °C	-30 °C	780 V	Laboratory	90.5 %
MEAN WELL USA Inc. WDR-60-24	CE EAC TUV UL	1	254 V	60 W	Adjustable Output	24 V	4.7 kV	AC or DC	2.5 A	550 VAC	180 VAC	85 °C	-30 °C	780 V	Laboratory	89 %
MEAN WELL USA Inc. WDR-60-5	CE EAC TUV UL	1	254 V	50 W	Adjustable Output	5 V	4.7 kV	AC or DC	10 A	550 VAC	180 VAC	85 °C	-30 °C	780 V	Laboratory	83.5 %
MEAN WELL USA Inc. WDR-60-12	CE EAC TUV UL	1	254 V	60 W	Adjustable Output	12 V	4.7 kV	AC or DC		550 VAC	180 VAC	85 °C	-30 °C	780 V	Laboratory	86.5 %	5 A
