LB15SKG01 Series

Catalog

SWITCH PUSHBUTTON SPDT 0.4VA 28V

Part	Mechanical Life	Electrical Life	Voltage Rating - DC	Mounting Type	Voltage Rating - AC	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Current Rating (Amps)	Circuit	Switch Function	Actuator Marking	Type	Actuator Type	Color - Actuator/Cap	Operating Temperature [Max]	Operating Temperature [Min]	Illumination Voltage (Nominal)	Termination Style	Illumination Type, Color
NKK Switches LB15SKG01-5C-JC	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	1.9 VDC	Solder Quick Connect - 0.110" (2.8mm)	LED Red
NKK Switches LB15SKG01-5C12-JB	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	12 VDC	Solder Quick Connect - 0.110" (2.8mm)	LED Red
NKK Switches LB15SKG01-5F-JB	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	2.1 VDC	Solder Quick Connect - 0.110" (2.8mm)	Green LED
NKK Switches LB15SKG01-A	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Standard	Button Square	Black	70 °C	-25 °C		Solder Quick Connect - 0.110" (2.8mm)
NKK Switches LB15SKG01-6B-JB	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	3.3 VDC	Solder Quick Connect - 0.110" (2.8mm)	LED White
NKK Switches LB15SKG01-1C-A	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Black	50 °C	-25 °C	1.9 VDC	Solder Quick Connect - 0.110" (2.8mm)	LED Red
NKK Switches LB15SKG01-5C24-JC	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	24 V	Solder Quick Connect - 0.110" (2.8mm)	LED Red
NKK Switches LB15SKG01-05-JC	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	5 VAC	Solder Quick Connect - 0.110" (2.8mm)	Incandescent Red
NKK Switches LB15SKG01-B	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Standard	Button Square	White	70 °C	-25 °C		Solder Quick Connect - 0.110" (2.8mm)
NKK Switches LB15SKG01-5D05-JD	1000000 Cycles	100000 Cycles	28 V	Panel Mount Snap-In	28 V	16.2 mm	16.2 mm	0.4 VA	SPDT	On-Mom	No Marking	Illuminated Standard	Button Square	Clear	50 °C	-25 °C	5 VDC	Solder Quick Connect - 0.110" (2.8mm)	Amber LED
