Barrier Terminal Blocks MAGNUM CB3 SERIES
Barrier Terminal Blocks MAGNUM CB3 SERIES
| Part | Number of Wire Entries | Color | Features | Bottom Termination | Wire Gauge [Max] | Wire Gauge [Min] | Number of Rows | Top Termination | Voltage Rating | Number of Circuits | Pitch | Pitch | Terminal Block Type | Current Rating (Amps) | Barrier Type | Mounting Type | Terminal Screw Material | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Terminal Screw Finish | Material - Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | 8 | Black | Flange | Solder Turret | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 8 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) | |||||||
 Eaton - Electronics Division | 3 | Black | Solder Turret | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 3 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) | Chassis Panel | Steel | -40 C | 105 ░C | UL94 V-0 | Zinc | Thermoplastic | |
Eaton - Electronics Division | 5 | Black | Flange | Solder Turret | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 5 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) | Chassis Panel | Steel | -40 C | 105 ░C | UL94 V-0 | Zinc | Thermoplastic |
 Eaton - Electronics Division | 14 | Black | PC Pin | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 14 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) | Through Hole | Steel | -40 C | 105 ░C | UL94 V-0 | Zinc | Thermoplastic | |
Eaton - Electronics Division | 3 | Black | PC Pin | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 3 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) | ||||||||
Eaton - Electronics Division | 8 | Black | PC Pin | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 8 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) | ||||||||
Eaton - Electronics Division | 10 | Black | Flange | PC Pin | 22 AWG | 12 AWG | 1 | Screws with Captive Plate | 600 V | 10 | 0.437 " | 11.1 mm | Barrier Block | 30 A | 3 Wall (Tri) |
