ISL9021A Series

250mA Single LDO with Low IQ, Low Noise and High PSRR LDO

Manufacturer: Renesas Electronics Corporation

Catalog

250mA Single LDO with Low IQ, Low Noise and High PSRR LDO

Part	Current - Quiescent (Iq)	Number of Regulators	Current - Output	Supplier Device Package	Mounting Type	Output Configuration	Control Features	Protection Features	Package / Case	Voltage - Output (Min/Fixed)	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Output Type	Voltage Dropout (Max) [Max]
Renesas Electronics Corporation ISL9021AIRUCZ-T7A	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	1.8 V	5.5 V	85 °C	-40 °C	1.81 mOhm
Renesas Electronics Corporation ISL9021AIRUCZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	1.8 V	5.5 V	85 °C	-40 °C	1.81 mOhm
Renesas Electronics Corporation ISL9021AIRUFZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	2.5 V	5.5 V	85 °C	-40 °C	1.81 mOhm	0.25 V
Renesas Electronics Corporation ISL9021AIIFZ-T	50 çA	1	250 mA	1.16x0.98 4-WLCSP	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start		2.5 V	5.5 V	85 °C	-40 °C	1.81 mOhm	0.25 V
Renesas Electronics Corporation ISL9021IRUBZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	1.5 V	5.5 V	85 °C	-40 °C	1.81 mOhm
Renesas Electronics Corporation ISL9021AIRUMZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN		5.5 V	85 °C	-40 °C	1.81 mOhm	0.25 V
Renesas Electronics Corporation ISL9021IRURZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	2.6 V	5.5 V	85 °C	-40 °C	1.81 mOhm	0.25 V
Renesas Electronics Corporation ISL9021IRUKZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	2.85 V	5.5 V	85 °C	-40 °C	1.81 mOhm	0.25 V
Renesas Electronics Corporation ISL9021AIRUMZ-T7A	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN		5.5 V	85 °C	-40 °C	1.81 mOhm	0.25 V
Renesas Electronics Corporation ISL9021AIRUWZ-T	50 çA	1	250 mA	6-UTDFN (1.6x1.6)	Surface Mount	Positive	Enable	Over Current Over Temperature Reverse Polarity Short Circuit Soft Start	6-UFDFN	1.2 V	5.5 V	85 °C	-40 °C	1.81 mOhm

Catalog

250mA Single LDO with Low IQ, Low Noise and High PSRR LDO

Description

The ISL9021A is a single LDO, which provides high performance, low input voltage and high PSRR. It delivers guaranteed continuous 250mA load current and is stable with 1µF to 4. 7µF of output capacitance (±30%) with an ESR range of 5mΩ to 400mΩ. The input voltage range for the ISL9021A is between 1. 5V to 5. 5V and the output voltage comes in many fixed voltage options with ±1. 8% accuracy over-temperature, line and load ranges. The ISL9021A has typical PSRR of 75dB @ 10kHz and 50dB @ 1MHz. The reverse current protection feature prevents current from flowing back to the power source when the output voltage is pulled higher than the input. The ISL9021A is offered in tiny 4-bump 0. 975mmx1. 155mm WLCSP and 1. 6mmx1. 6mm 6 Ld µTDFN packages.
