SS71800 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
CONNECTOR, RJ45, JACK, 8P8C, TH
| Part | Housing Material | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Ratings | Contact Finish | Number of Positions/Contacts | Number of Rows | Number of Ports | Tab Direction | Shielding | LED Color | Mounting Type | Connector Type | Orientation | Termination | Features | Contact Material | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Thermoplastic | 50 µin | 1.27 µm | 85 °C | -40 C | Cat5 | Gold | 8p8c (RJ45 Ethernet) | 1 | 1 | Down | EMI Finger Shielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Board Lock | Copper Alloy | |
 Bel Fuse Inc. | Thermoplastic | 30 Áin | 0.76 Ám | 85 °C | -40 C | Cat5e | Gold | 8p8c (RJ45 Ethernet) | 1 | 1 | Down | Unshielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Board Lock EPP918A | Copper Alloy | |
 Bel Fuse Inc. | Thermoplastic | 30 Áin | 0.76 Ám | 85 °C | -40 C | Cat5e | Gold | 8p8c (RJ45 Ethernet) | 1 | 4 | Down | EMI Finger Shielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Board Guide | Copper Alloy | |
Bel Fuse Inc. | Thermoplastic | 30 Áin | 0.76 Ám | 85 °C | -40 C | Cat5 | Gold | 8p8c (RJ45 Ethernet) | 1 | 1 | Down | EMI Finger Shielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Board Lock | Copper Alloy | |
Bel Fuse Inc. | Glass Filled Thermoplastic | 85 °C | -40 C | Gold | Jack | Copper Alloy | ||||||||||||||
 Bel Fuse Inc. | Thermoplastic | 50 µin | 1.27 µm | 85 °C | -40 C | Cat5e | Gold | 8p8c (RJ45 Ethernet) | 1 | 1 | Down | EMI Finger Shielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Board Lock EPP918A | Copper Alloy | |
 Bel Fuse Inc. | Thermoplastic | 50 µin | 1.27 µm | 85 °C | -40 C | Cat5e | Gold | 8p8c (RJ45 Ethernet) | 1 | 1 | User Selectable | Shielded | Does Not Contain LED | Through Hole | Jack | Solder | Board Lock EPP918A | Copper Alloy | Vertical | |
 Bel Fuse Inc. | Thermoplastic | 50 µin | 1.27 µm | Cat5e | Gold | 8p8c (RJ45 Ethernet) | 1 | 8 | Down | EMI Finger Shielded | Does Not Contain LED | Panel Mount Through Hole | Jack | 90 ° | Solder | Board Guide | Copper Alloy | |||
 Bel Fuse Inc. | Glass Filled Thermoplastic | 85 °C | -40 C | Cat5e | Gold | 1 | 2 | Down | Shielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Copper Alloy | |||||
Bel Fuse Inc. | Thermoplastic | 50 µin | 1.27 µm | 85 °C | -40 C | Cat5e | Gold | 8p8c (RJ45 Ethernet) | 1 | 1 | Down | Shielded | Does Not Contain LED | Through Hole | Jack | 90 ° | Solder | Board Lock | Copper Alloy |
