82_MCX Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
RF COAX CONN, JACK, PCB, 50 OHM ROHS COMPLIANT: YES
| Part | Body Material | Voltage Rating | Operating Temperature [Max] | Operating Temperature [Min] | Body Finish | Mating Cycles | Center Contact Plating | Dielectric Material | Housing Color | Contact Termination | Frequency - Max [Max] | Center Contact Material | Number of Ports | Connector Type | Fastening Type | Impedance | Mounting Type | Connector Style | Shield Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Through Hole | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 165 °C | -65 ░C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Through Hole | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Through Hole | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Surface Mount | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Surface Mount | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 165 °C | -65 ░C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 75 Ohms | Board Edge Cutout Through Hole | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 165 °C | -65 ░C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Through Hole | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Board Edge Cutout Surface Mount | MCX | Solder |
 Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 75 Ohms | Through Hole | MCX | Solder |
Huber+Suhner, Inc. | Brass | 170 V | 155 C | -55 C | Gold | 500 | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Solder | 6000 MHz | Beryllium Copper | 1 | Female Socket Jack | Snap-On | 50 Ohms | Board Edge Cutout Surface Mount | MCX | Solder |
