DBTC Series

Catalog

SIGNAL CONDITIONING DIR COUP / SURF MT/TOPHAT ROHS

Part	Power - Max [Max]	Coupler Type	Frequency [Min]	Frequency [Max]	Applications	Package / Case	Coupling Factor	Return Loss
Mini-Circuits DBTC-10-4-75X+	1 W	Standard	5 MHz	1 GHz	General Purpose	5-SMD Module	10.5 dB	25.51 dB
Mini-Circuits DBTC-7-152X+	1 W	Standard	10 MHz	1.5 GHz	Cellular	5-SMD Module	7 dB	46.44 dB
Mini-Circuits DBTC-7-152+	1 W	Standard	10 MHz	1.5 GHz	Cellular	5-SMD Module	7 dB	46.44 dB
Mini-Circuits DBTC-12-4-75+	1 W	Standard	5 MHz	1.2 GHz	CATV	5-SMD Module	12 dB	26.61 dB
Mini-Circuits DBTC-13-4L+	1 W	Standard	5 MHz	1 GHz	Cellular	5-SMD Module	13 dB	32.43 dB
Mini-Circuits DBTC-18-4-75L+	1 W	Standard	5 MHz	1 GHz	General Purpose	5-SMD Module	18.2 dB	24.29 dB
Mini-Circuits DBTC-9-4+	1 W	Standard	5 MHz	1 GHz	Cellular	5-SMD Module	9 dB	32.7 dB
