WSE12 Series

Catalog

SENSOR THROUGH-BEAM 15M PNP

Part	Ingress Protection	Adjustment Turns	Adjustment Type	Output Configuration	Sensing Distance Minimum	Sensing Distance Maximum	Operating Temperature (Max)	Operating Temperature (Min)	Sensing Method	Response Time	Light Source	Connection Method	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Light Source Wavelength (Red)	Sensing Distance	Cable Length	Light Source Wavelength (Infrared)
SICK, Inc. 1041459	IP66 IP67 IP69K	5 turn	Adjustable Potentiometer	Dark-ON Light-ON Light-ON - Selectable PNP PNP - Dark-ON Selectable	0 cm	590.551 "	60 °C	-40 °C	Through-Beam	330 µs	Red LED	4POS Connector M12	10 VDC	30 VDC
SICK, Inc. 1041462	IP67 IP69K		Adjustable Potentiometer	Light-ON NPN - Dark-ON			50 °C	-10 °C	Through-Beam	200 µs	Red	Connector M12	10 VDC	30 VDC	640 nm	0.394 "
SICK, Inc. 1041464	IP66	5 turn	Adjustable Potentiometer	PNP			60 °C	-40 °C	Through-Beam	330 µs	Infrared	Cable	10 VDC	30 VDC		787.402 "	78.74 in	880 nm
SICK, Inc. 1041465	IP66	5 turn	Adjustable Potentiometer	PNP			60 °C	-40 °C	Through-Beam	330 µs	Infrared	Connector M12	10 VDC	30 VDC		787.402 "		880 nm
SICK, Inc. WSE12-3P2431T01	IP67 IP69K		Adjustable Potentiometer	Light-ON NPN - Dark-ON			50 °C	-10 °C	Through-Beam	200 µs	Red	Connector M12	10 VDC	30 VDC	640 nm	0.394 "
