R60MI Series

Manufacturer: KEMET

Catalog

CAP FILM 0.1UF 400V PET 10%( 18 X 5 X 11MM) RADIAL WOUND 15MM 105°C BAG AUTOMOTIVE AEC-Q200

Part	Voltage Rating - DC	Termination	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Ratings	Mounting Type	Capacitance	Tolerance	Lead Spacing	Lead Spacing	Voltage Rating - AC	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Applications	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [y]	Height - Seated (Max) [Max] [z]
KEMET R60MI31004030K	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	100000 pF	10 %	15 mm	0.591 in	200 V	0.709 in	5 mm	18 mm	0.197 "	Automotive	11.1 mm	0.437 in
KEMET R60MI32205040K	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.22 µF	10 %	15 mm	0.591 in	200 V	0.709 in	5 mm	18 mm	0.197 "	Automotive	11.1 mm	0.437 in
KEMET R60MI34705040K	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.47 µF	10 %	15 mm	0.591 in	200 V	0.709 in		18 mm	0.295 in	Automotive			7.5 mm
KEMET R60MI32205040J	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.22 µF	5 %	15 mm	0.591 in	200 V	0.709 in	5 mm	18 mm	0.197 "	Automotive	11.1 mm	0.437 in
KEMET R60MI31505030K	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.15 ÁF	10 %	15 mm	0.591 in	200 V	0.709 in	5 mm	18 mm	0.197 "	Automotive	11.1 mm	0.437 in
KEMET R60MI3330DQ30K	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.33 µF	10 %	15 mm	0.591 in	200 V	0.709 in		18 mm	0.295 in	Automotive			7.5 mm
KEMET R60MI31004030J	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	100000 pF	5 %	15 mm	0.591 in	200 V	0.709 in	5 mm	18 mm	0.197 "	Automotive	11.1 mm	0.437 in
KEMET R60MI3470AA30K	400 V	PC Pins	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.47 µF	10 %	15 mm	0.591 in	200 V	0.709 in		18 mm	0.335 in	Automotive	14.6 mm		8.5 mm	0.575 in
KEMET R60MI33305030J	400 V	PC Pins	Metallized - Stacked Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	Radial	AEC-Q200	Through Hole	0.33 µF	5 %	15 mm	0.591 in	200 V	0.709 in		18 mm	0.295 in	Automotive			7.5 mm
