FCC Series

Manufacturer: OptiFuse

Catalog

FUSE CERAMIC 2.5A 250VAC 5X20MM

Part	Melting I˛t	DC Cold Resistance	Response Time	Mounting Type	Melting I²t	Operating Temperature [Min]	Operating Temperature [Max]	Breaking Capacity @ Rated Voltage	Voltage Rating - AC	Fuse Type	Package / Case [x]	Package / Case [y]	Current Rating (Amps)	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [diameter]	Approval Agency
OptiFuse FCC-2.5A	3.6	0.0569 Ohms	Fast Blow	Requires Holder	3.6	-55 C	125 °C	100 A	250 V	Cartridge Ceramic	5 mm	20 mm	2.5 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-3.5A			Fast Blow	Requires Holder		-55 C	125 °C	100 A	250 V	Cartridge Ceramic	5 mm	20 mm	3.5 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-6.3A	48.237	0.0129 Ohms	Fast Blow	Requires Holder		-55 C	125 °C	200 A	250 V	Cartridge Ceramic	5 mm	20 mm	6.3 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-10A	166.1	0.0074 Ohms	Fast Blow	Requires Holder		-55 C	125 °C	200 A	250 V	Cartridge Ceramic	5 mm	20 mm	10 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-5A	22.303	0.0209 Ohms	Fast Blow	Requires Holder		-55 C	125 °C	200 A	250 V	Cartridge Ceramic	5 mm	20 mm	5 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-6A			Fast Blow	Requires Holder		-55 C	125 °C	200 A	250 V	Cartridge Ceramic	5 mm	20 mm	6 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-15A	435.98 I˛t	0.0044 Ohms	Fast Blow	Requires Holder	435.98	-55 C	125 °C	750 A	250 V	Cartridge Ceramic	5 mm	20 mm	15 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
OptiFuse FCC-2A		0.0576 Ohms	Fast Blow	Requires Holder		-55 C	125 °C	100 A	250 V	Cartridge Ceramic	5 mm	20 mm	2 A	20 mm	0.205 in	0.787 "	5.2 mm	cULus UL 248
