250 Series

Manufacturer: Ohmite

Catalog

WIREWOUND RESISTORS - CHASSIS MOUNT 30WATT 10OHM 5% HIGH POWER

Part	Package / Case	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	Coating, Housing Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Temperature Coefficient	Resistance	Mounting Feature	Composition	Tolerance	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Lead Style	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Temperature Coefficient	Operating Temperature
Ohmite F30J10RE	Radial Flat Oval	30 Watts	-55 C	350 °C	Vitreous Enamel Coated	14.29 mm	0.563 in	±400ppm/°C	10 Ohms	Flange Braces Right Angle	Wirewound	5 %	1 "	31.75 mm	1.25 in	25.4 mm	Solder Lugs
Ohmite F10J500E	Radial Flat Oval	10 W	-55 C	350 °C	Vitreous Enamel Coated				0.5 kOhms	Flange Braces Right Angle	Wirewound	5 %	0.375 in	19.05 mm	0.75 in	9.53 mm	Solder Lugs	0.375 in	9.53 mm	260 ppm/°C
Ohmite F55J5R0E	Radial Flat Oval	55 W	-55 C	350 °C	Vitreous Enamel Coated	14.29 mm	0.563 in	±400ppm/°C	5 Ohms	Flange Braces Right Angle	Wirewound	5 %	1 "	88.9 mm	3.5 "	25.4 mm	Solder Lugs
Ohmite F40J25RE	Radial Flat Oval	40 W	-55 C	350 °C	Vitreous Enamel Coated	14.29 mm	0.563 in		25 Ohms	Flange Braces Right Angle	Wirewound	5 %	1 "	50.8 mm	2 in	25.4 mm	Solder Lugs			260 ppm/°C
Ohmite F20J1K25E	Radial Flat Oval	20 W	-55 C	350 °C	Vitreous Enamel Coated				1.25 kOhms	Flange Braces Right Angle	Wirewound	5 %	0.375 in	50.8 mm	2 in	9.53 mm	Solder Lugs	0.375 in	9.53 mm	260 ppm/°C
Ohmite F40J2R0E	Radial Flat Oval	40 W	-55 C	350 °C	Vitreous Enamel Coated	14.29 mm	0.563 in	±400ppm/°C	2 Ohms	Flange Braces Right Angle	Wirewound	5 %	1 "	50.8 mm	2 in	25.4 mm	Solder Lugs
Ohmite F10J1K5E	Radial Flat Oval	10 W			Vitreous Enamel Coated				1500 Ohms	Flange Braces Right Angle	Wirewound	5 %	0.375 in	19.05 mm	0.75 in	9.53 mm	Solder Lugs	0.375 in	9.53 mm	260 ppm/°C	350 °C
Ohmite F10J2R0E	Radial Flat Oval	10 W	-55 C	350 °C	Vitreous Enamel Coated			±400ppm/°C	2 Ohms	Flange Braces Right Angle	Wirewound	5 %	0.375 in	19.05 mm	0.75 in	9.53 mm	Solder Lugs	0.375 in	9.53 mm		350 °C
Ohmite F20J10RE	Radial Flat Oval	20 W	-55 C	350 °C	Vitreous Enamel Coated			±400ppm/°C	10 Ohms	Flange Braces Right Angle	Wirewound	5 %	0.375 in	50.8 mm	2 in	9.53 mm	Solder Lugs	0.375 in	9.53 mm		350 °C
Ohmite F55J750E	Radial Flat Oval	55 W	-55 C	350 °C	Vitreous Enamel Coated	14.29 mm	0.563 in		750 Ohms	Flange Braces Right Angle	Wirewound	5 %	1 "	88.9 mm	3.5 "	25.4 mm	Solder Lugs			260 ppm/°C
