EHD-RD Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
DC DC CONVERTER -24V 4W
| Part | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Type | Applications | Voltage - Input (Max) [Max] | Number of Outputs | Voltage - Input (Min) [Min] | Mounting Type | Power (Watts) | Efficiency | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output (Max) [Max] | Package / Case | Package / Case | Voltage - Output 1 | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | 1.11 in | 17.9 mm | 0.24 " | 6 mm | 0.7 " | 28.2 mm | Non-Isolated PoL Module | ITE (Commercial) | -200 V | 1 | -113 V | Through Hole | 4 W | 84 % | 85 °C | -20 C | 180 mA | 5 Leads | 10-SIP Module | |||
 Panasonic Industrial Automation Sales | 1.11 in | 17.9 mm | 0.35 " | 9 mm | 0.7 " | 28.2 mm | Non-Isolated PoL Module | ITE (Commercial) | -170 V | 1 | -113 V | Through Hole | 5 W | 80 % | 80 C | -25 °C | 150 mA | 5 Leads | 10-SIP Module | -32 V | ||
 Panasonic Industrial Automation Sales | 1.11 in | 17.9 mm | 0.24 " | 6 mm | 0.7 " | 28.2 mm | Non-Isolated PoL Module | ITE (Commercial) | 170 V | 1 | 113 V | Through Hole | 5 W | 84 % | 85 °C | -20 C | 200 mA | 5 Leads | 10-SIP Module | 24.6 V | ||
 Panasonic Industrial Automation Sales | 1.2 " | 0.39 " | 0.74 in | 30.5 mm | Non-Isolated PoL Module | ITE (Commercial) | 170 V | 1 | 113 V | Through Hole | 2 W | 75 % | 85 °C | -25 °C | 100 mA | 9 PC Pad | 10-SIP Module | 20 V | 18.9 mm | 10 mm | ||
 Panasonic Industrial Automation Sales | Non-Isolated PoL Module | ITE (Commercial) | 338 V | 1 | 225 V | Through Hole | 5 W | 75 % | 80 C | -20 C | 400 mA | 8 Leads | 15-SIP Module | 12 V |
