SCP7QT78 Series

Catalog

LED LM101B COOL WHITE 5700K SMD

Part	Thermal Resistance of Package	Voltage - Forward (Vf) (Typ)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Viewing Angle	Mounting Type	Supplier Device Package	Current - Max [Max]	Lumens/Watt @ Current - Test	CCT (K)	CCT (K)	CRI (Color Rendering Index)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Current - Test	Flux @ 25°C, Current - Test [Min]	Flux @ 25°C, Current - Test [Max]	Flux @ 25°C, Current - Test	Package / Case	Color	Flux @ 85°C, Current - Test [Max]	Flux @ 85°C, Current - Test [Min]	Package / Case	Size / Dimension [y]
Samsung Semiconductor, Inc. SCP7QT78HEL1QUS06E	2 °C/W	2.8 V	0.018 "	0.45 mm	120 °	Surface Mount	SMD	350 mA	192 lm/W	5700 K	3-Step MacAdam Ellipse	70	0.067 in	0.067 in	1.7 mm	1.7 mm	65 mA	33 lm	37 lm	35 lm	0606 (1616 Metric)	Cool White
Samsung Semiconductor, Inc. SCP7QT78HPL1QLS06E	2 °C/W	2.9 V	0.017 "	0.42 mm	150 °	Surface Mount	SMD	450 mA	149 lm/W	5700 K		70			0.046 in 1.18 mm	0.046 in 1.18 mm	150 mA				0505	Cool White	71 lm	59 lm	1313
Samsung Semiconductor, Inc. SCP7QT78HEL1QLS06E	2 °C/W	2.8 V	0.018 "	0.45 mm	120 °	Surface Mount	SMD	350 mA	192 lm/W	5700 K		70	0.067 in	0.067 in	1.7 mm	1.7 mm	65 mA	33 lm	37 lm	35 lm	0606 (1616 Metric)	Cool White
Samsung Semiconductor, Inc. SCP7QT78HPL1QUS06E	2 °C/W	2.9 V	0.018 "	0.45 mm	150 °	Surface Mount	SMD	450 mA	149 lm/W	5700 K		70	0.045 "	0.045 in	1.15 mm		150 mA				0505	Cool White	71 lm	59 lm	1313	1.15 mm
