ulv4 Series

Manufacturer: E-Switch

Catalog

SWITCH: VANDAL RESISTANT; POS: 2; SPDT; 3A/250VAC; IP67; ON-ON; ULV4

Part	Illumination Voltage (Nominal)	Circuit	Operating Temperature [Max]	Operating Temperature [Min]	Actuator Type	Switch Function	Type	Color - Actuator/Cap	Termination Style	Current Rating (Amps)	Illumination Type, Color	Mounting Type	Voltage Rating - AC	Ingress Protection	Panel Cutout Dimensions [diameter]	Mechanical Life	Electrical Life
E-Switch ULV4F23SS505	24 V	SPDT	55 °C	-20 ░C	Button Flush Round	On-On	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED White	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4F2BSS531WA178	3 VDC	SPDT	55 °C	-20 ░C	Button Flush Round	On-Mom	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	Green LED	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4F2BSS331	3 VDC	SPDT	55 °C	-20 ░C	Button Flush Round	On-Mom	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	Green LED	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm	1000000 Cycles	50000 Cycles
E-Switch ULV4F2BSS305	24 V	SPDT	55 °C	-20 ░C	Button Flush Round	On-Mom	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED White	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4FWBSS345	24 V	SPDT	55 °C	-20 ░C	Button Flush Round	On-Mom	Anti-Vandal Illuminated	Silver	Wire Leads	3 A	Blue LED	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4F2GSS313	6 VDC	DPDT	55 °C	-20 ░C	Button Flush Round	On-On	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED Red	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4F23SS314	12 VDC	SPDT	55 °C	-20 ░C	Button Flush Round	On-On	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED Red	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4F23SS316	110 VAC	SPDT	55 °C	-20 ░C	Button Flush Round	On-On	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED Red	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19 mm
E-Switch ULV4F2GSS314	12 VDC	DPDT	55 °C	-20 ░C	Button Flush Round	On-On	Anti-Vandal Illuminated	Silver	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED Red	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm
E-Switch ULV4F2G11G515	24 V	DPDT	55 °C	-20 ░C	Button Flush Round	On-On	Anti-Vandal Illuminated	Black	Solder Quick Connect - 0.110" (2.8mm)	3 A	LED Red	Panel Mount Front	125 V	IP67 - Dust Tight Waterproof	19.2 mm	500000 Cycles	50000 Cycles
