ED1100 Series

Catalog

TERM BLOCK PLUG 16POS 90DEG 5MM

Part	Torque - Screw	Torque - Screw	Material Flammability Rating	Housing Material	Screw Size	Insulation Height	Insulation Height	Wire Strip Length	Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Type	Features	Plug Wire Entry	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Number of Levels	Wire Gauge or Range - mm²	Voltage - UL	Color	Positions Per Level	Pitch	Pitch	Mounting Type	Number of Positions	Wire Gauge or Range - mm˛
On Shore Technology Inc. ED1100/16	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	16	0.197 in	5 mm	Free Hanging (In-Line)	16
On Shore Technology Inc. ED1100/9	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	9	0.197 in	5 mm	Free Hanging (In-Line)	9	2.5 mm˛
On Shore Technology Inc. ED1100/5	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	5	0.197 in	5 mm	Free Hanging (In-Line)	5
On Shore Technology Inc. ED1100/6	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	6	0.197 in	5 mm	Free Hanging (In-Line)	6
On Shore Technology Inc. ED1100/12	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	12	0.197 in	5 mm	Free Hanging (In-Line)	12	2.5 mm˛
On Shore Technology Inc. ED1100/10	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	10	0.197 in	5 mm	Free Hanging (In-Line)	10	2.5 mm˛
On Shore Technology Inc. ED1100/3	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	3	0.197 in	5 mm	Free Hanging (In-Line)
On Shore Technology Inc. ED1100/4	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	4	0.197 in	5 mm	Free Hanging (In-Line)	4
On Shore Technology Inc. ED1100/2	4.4 Lb-In	0.5 Nm	UL94 V-0	Polyamide (PA) Nylon	M3	26.5 mm	1.043 in	7 mm	Copper Tin Alloy	-30 ░C	105 ░C	Screw	Plug Female Sockets	Retention Latches (Wire Side)	90 °	22 AWG	10 AWG	1	2.5 mm²	300 V	Green	2	0.197 in	5 mm	Free Hanging (In-Line)	2
