2232264 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN RCPT HSG 10POS 6.00MM
| Part | Insulation Material | Mounting Type | Note | Connector Type | Row Spacing | Row Spacing | Fastening Type | Number of Positions | Contact Type | Features | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Contact Termination | Pitch [x] | Pitch [x] | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Glass Filled Nylon Polyamide (PA) | Panel Mount Snap-In | Contacts Not Included | Receptacle | 8.1 mm | 0.319 in | Latch Lock | 10 | Tab | Glow Wire Compliant | 105 ░C | -55 °C | 2 | Crimp | 0.236 in | 6 mm | |
 TE Connectivity Raychem Cable Protection | Glass Filled Nylon Polyamide (PA) | Panel Mount Snap-In | Contacts Not Included | Receptacle | 8.1 mm | 0.319 in | Latch Lock | 8 | Tab | Glow Wire Compliant | 105 ░C | -55 °C | 2 | Crimp | 0.236 in | 6 mm | Brown |
TE Connectivity Raychem Cable Protection | Glass Filled Nylon Polyamide (PA) | Panel Mount Snap-In | Contacts Not Included | Receptacle | 8.1 mm | 0.319 in | Latch Lock | 8 | Tab | Glow Wire Compliant | 105 ░C | -55 °C | 2 | Crimp | 0.236 in | 6 mm | |
 TE Connectivity Raychem Cable Protection | Glass Filled Nylon Polyamide (PA) | Panel Mount Snap-In | Contacts Not Included | Receptacle | 8.1 mm | 0.319 in | Latch Lock | 8 | Tab | Glow Wire Compliant | 105 ░C | -55 °C | 2 | Crimp | 0.236 in | 6 mm | Gray |
