PE4000 Series
Manufacturer: Pasternack
Beta
⌘K
BNC(F) BLKHD MNT
| Part | Center Contact Plating | Body Finish | Body Material | Mounting Feature | Center Contact Material | Number of Ports | Housing Color | Contact Termination | Connector Style | Frequency - Max [Max] | Mounting Type | Fastening Type | Impedance | Shield Termination | Connector Type | Dielectric Material | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pasternack | Gold | Nickel | Zinc | Bulkhead - Front Side Nut | Brass | 1 | Silver | Solder | BNC | 12 GHz | Panel Mount Through Hole | Bayonet Lock | 75 Ohms | Solder | Female Socket Jack | ||
 Pasternack | Gold | Nickel | Brass | Brass | 1 | Silver | Crimp | BNC | 12 GHz | Free Hanging (In-Line) | Bayonet Lock | 75 Ohms | Solder | Plug Male Pin | Polytetrafluoroethylene (PTFE) | 4694R Belden 1694A RG-6 | |
 Pasternack | Gold | Nickel | Brass | Bulkhead - Front Side Nut | Brass | 1 | Silver | Solder | BNC | 12 GHz | Panel Mount Right Angle Through Hole | Bayonet Lock | 75 Ohms | Solder | Female Socket Jack | Polymethylpentene (PMP) | |
 Pasternack | Gold | Nickel | Brass | Brass | 1 | Silver | Crimp | BNC HD | 12 GHz | Free Hanging (In-Line) | Bayonet Lock | 75 Ohms | Solder | Plug Male Pin | Polytetrafluoroethylene (PTFE) | 4694R Belden 1694A RG-6 | |
 Pasternack | Gold | Gold | Brass | Brass | 1 | Gold | Crimp | 1.0/2.3 | 12 GHz | Free Hanging (In-Line) | Snap-On | 75 Ohms | Solder | Plug Male Pin | Polytetrafluoroethylene (PTFE) | 4855R Belden 1855A | |
 Pasternack | Gold | Nickel | Brass | Brass | 1 | Silver | Solder | BNC | 12 GHz | Through Hole | Bayonet Lock | 75 Ohms | Solder | Female Socket Jack | Polytetrafluoroethylene (PTFE) | ||
 Pasternack | Gold | Nickel | Brass | Brass | 1 | Silver | Crimp | BNC HD | 12 GHz | Free Hanging (In-Line) | Bayonet Lock | 75 Ohms | Solder | Plug Male Pin | Polytetrafluoroethylene (PTFE) | 4855R Belden 1855A | |
 Pasternack | Gold | Nickel | Brass | Brass | 1 | Silver | Crimp | 1.0/2.3 | 12 GHz | Free Hanging (In-Line) | Snap-On | 75 Ohms | Solder | Plug Male Pin | Polytetrafluoroethylene (PTFE) | 4694R Belden 1694A RG-6 | |
 Pasternack | Gold | Zinc | Bulkhead - Front Side Nut | Brass | 1 | Silver | Solder | BNC | 12 GHz | Panel Mount Right Angle Through Hole | Bayonet Lock | 75 Ohms | Solder | Female Socket Jack | Liquid Crystal Polymer (LCP) |
