846-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 38POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Mounting Type | Number of Positions | Gender | Card Type | Number of Rows [custom] | Color | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Read Out | Contact Material | Pitch | Pitch | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Termination | Termination Rows | Number of Rows | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 19 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Right Angle Through Hole | 38 | Female | Non Specified - Dual Edge | 2 | Green | 0.25 Ám | 10 Áin | Gold | Dual | Copper Alloy | 3.18 mm | 0.125 in | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Solder | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Single Edge | Green | 0.25 Ám | 10 Áin | Gold | Single | Copper Alloy | 3.18 mm | 0.125 in | Solder Eyelet(s) | 1 | 1 | 38 | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 19 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Dual Edge | 2 | Green | 0.25 Ám | 10 Áin | Gold | Dual | Copper Alloy | 3.18 mm | 0.125 in | Flush Mount M3 Threaded Insert Top Opening | Solder Eyelet(s) | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 19 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Board Edge Straddle Mount | 38 | Female | Non Specified - Dual Edge | 2 | Green | 0.25 Ám | 10 Áin | Gold | Dual | Copper Alloy | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | Solder Eyelet(s) | Card Extender | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Right Angle Through Hole | 38 | Female | Non Specified - Single Edge | Green | 0.25 Ám | 10 Áin | Gold | Single | Copper Alloy | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | Solder | 1 | 1 | 38 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 19 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Dual Edge | 2 | Green | 0.25 Ám | 10 Áin | Gold | Dual | Copper Alloy | 3.18 mm | 0.125 in | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Solder | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Single Edge | Green | 0.25 Ám | 10 Áin | Gold | Single | Copper Alloy | 3.18 mm | 0.125 in | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Solder | 1 | 1 | 38 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Single Edge | Green | 0.25 Ám | 10 Áin | Gold | Single | Copper Alloy | 3.18 mm | 0.125 in | 0.128 " | 3.25 mm | Solder | 1 | 1 | 38 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Single Edge | Green | 0.25 Ám | 10 Áin | Gold | Single | Copper Alloy | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | 1 | 1 | 38 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 19 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | 38 | Female | Non Specified - Dual Edge | 2 | Green | 0.25 Ám | 10 Áin | Gold | Dual | Copper Alloy | 3.18 mm | 0.125 in | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Wire Wrap |
