SRP1510CA Series
Manufacturer: Bourns Inc.
Beta
⌘K
INDUCTOR POWER SHIELDED WIREWOUND 22UH 20% 100KHZ 30Q-FACTOR METAL ALLOY POWDER 16A 0.0158OHM DCR AUTOMOTIVE AEC-Q200 T/R
| Part | Inductance Frequency - Test | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Shielding | Tolerance | Current Rating (Amps) | Inductance | Frequency - Self Resonant | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Ratings | DC Resistance (DCR) [Max] | Q @ Freq | Current - Saturation (Isat) | Material - Core | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 100 kHz | 10 mm | 0.394 in | Shielded | 20 % | 16 A | 22 µH | 5 MHz | 0.61 in | 15.5 mm | 0.65 in | 16.5 mm | Nonstandard | 155 C | -55 C | AEC-Q200 | 15.8 mOhm | 30 100 kHz | 20 A | Metal | Surface Mount |
 Bourns Inc. | 100 kHz | 10 mm | 0.394 in | Shielded | 20 % | 24 A | 10 µH | 8 MHz | 0.61 in | 15.5 mm | 0.65 in | 16.5 mm | Nonstandard | 155 C | -55 C | AEC-Q200 | 8.6 mOhm | 30 100 kHz | 29 A | Metal | Surface Mount |
