KC-LINK with KONNEKT Series

Manufacturer: KEMET

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - SMD/SMT 1200V 0.024UF 2220 KCLINK KONNEKT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Capacitance	Applications	Features	Tolerance	Package / Case	Package / Case	Temperature Coefficient	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Mounting Type	Voltage - Rated	Voltage - Rated	Thickness (Max) [Max]	Thickness (Max) [Max]	Ratings	Size / Dimension [y]
KEMET CKC21C243KEGLC7810	-55 C	150 °C	0.024 µF	General Purpose	High Temperature High Voltage Low ESL	10 %	2220	5750 Metric	C0G NP0	5.7 mm	0.224 "	0.197 "	5 mm	MLCC Surface Mount	1.2 kV	1200 V	0.213 in	5.4 mm
KEMET CKC21C204KWGLC7210	-55 C	150 °C	0.2 µF	General Purpose	High Temperature High Voltage Low ESL	10 %	2220	5750 Metric	C0G NP0	5.7 mm	0.224 "	0.197 "	5 mm	MLCC Surface Mount		650 V	0.213 in	5.4 mm
KEMET CKC18C943KWGLCAUTO	-55 C	150 °C	0.094 µF	Automotive	High Temperature High Voltage Low ESL	10 %	1812 (4532 Metric)		C0G NP0	4.5 mm	0.177 in	0.126 in		MLCC Surface Mount		650 V			AEC-Q200	3.2 mm
KEMET CKC21C143KJGLCAUTO7805	-55 C	150 °C	0.014 µF	Automotive	High Temperature High Voltage Low ESL	10 %	2220	5750 Metric	C0G NP0	5.7 mm	0.224 "	0.197 "	5 mm	MLCC Surface Mount	1.7 kV	1700 V	0.213 in	5.4 mm	AEC-Q200
KEMET CKC21C243KEGLC7805	-55 C	150 °C	0.024 µF	General Purpose	High Temperature High Voltage Low ESL	10 %	2220	5750 Metric	C0G NP0	5.7 mm	0.224 "	0.197 "	5 mm	MLCC Surface Mount	1.2 kV	1200 V	0.213 in	5.4 mm
